Item - Check Valves Check Valve, Flow Design Single, Mechanism and Body Design Inline Spring Piston, Body Material - Valves Brass, Buna-N, Stainless Steel, Pipe or Tube Size 3/8 in, Connection Type FNPT x FNPT, Cracking Pressure 2.0 psi, Mounting Orientation Horizontal, Vertical, Seal Material Buna-N, Max. Temp. - Valves 194 Degrees F, Min. Temp. - Valves 40 Degrees F, Max. Water Pressure - Valves 5,800 psi, Max. Steam Pressure - Valves Not Rated, Seat Material Stainless Steel.
- Pipe Size: 3/8"
- Hex Size: 15/16"
- Connection Type: FNPT x FNPT
- Body Material: Brass
- Flow Design: Single
- Max. Temp.: 194 Degrees F
- Item - Check Valves: Check Valve
- Max. Pressure: 5800 psi
- Mechanism and Body Design: Inline Spring Piston
- Cracking Pressure - Check Valves: 2.000 psi
- Width: 1-1/16"
- Length: 2-21/64"
- Sub-Category: Stainless Steel
- Flow: 10.5 gpm
- Spring Material: Stainless Steel
- Full Flow - Valves: Yes
- Max. Water Pressure - Valves: 5800 psi
- Application - Valves: High Pressure
- Pipe or Tube Size - Check Valves: 3/8 in
- Item: Spring Check Valve
- Material of Construction: Brass/Stainless Steel/Buna N
- Mounting Position: Vertical or Horizontal
- Seal Material: Buna N
- Max. Water Pressure: 5800 psi
- Cracking Pressure: 2 psi
- Max. Steam Pressure - Valves: Not Rated
- Connection Type - Check Valves: FNPT x FNPT
- Mounting Orientation - Check Valves: Horizontal, Vertical
- Size: 3/8"
- Min. Temp. - Valves: 40 Degrees F
- Seat Material: Stainless Steel
- Body Material - Valves: Brass, Buna-N, Stainless Steel
- Overall Height: 1-1/16"
- Flow - Valves: 10.50 gpm
- Seat Material - Check Valves: Stainless Steel
- Seal Material - Check Valves: Buna-N
- Max. Temp. - Valves: 194 Degrees F
- Spring Material - Check Valves: Stainless Steel
- Mounting Orientation: Horizontal, Vertical
- Pipe or Tube Size: 3/8 in
- Length (Straight Wireway): 2 21/64 in
- Country of Origin (subject to change): Italy
