OVERVIEW & BENEFITS
The 3/8″ Fixed Acid Chemical Injector (22.0320) is designed for safe and efficient downstream injection of low pH chemicals, including acid-based solutions and specialty cleaners. This injector features a fixed 1.8mm orifice, ideal for systems operating within a specific flow range and requiring consistent chemical draw.
Engineered for softwash and pressure washing applications, the 22.0320 model is built with acid-resistant internals for long-lasting performance even with harsh cleaning agents like degreasers and brighteners.
Key Features:
-
Inlet/Outlet Size: 3/8″ Male NPT
-
Orifice Size: 1.8mm (fixed)
-
Chemical Compatibility: Designed for acid and low pH solutions
-
Use Case: Downstream injection for softwash, fleet washing, restoration
-
Durable, corrosion- and acid-resistant construction
-
Consistent chemical draw rate – no adjustment needed
Specifications:
-
Model: 22.0320
-
Flow Range: ~1.5–3.5 GPM (varies by pressure)
-
Pressure Rating: Up to 4000 PSI
-
Temperature Rating: Up to 180°F
-
Thread Type: 3/8″ Male NPT inlet/outlet
-
Draw Rate: Fixed (approx. 10–20% depending on flow/pressure)
